Key Features & Advantages
- Full Head, Wide Voltage Design: A key performance feature allowing stable operation across the pump’s entire performance range. It is specifically designed to withstand power supply fluctuations, ensuring reliable operation in areas with unstable grid conditions.
- Single-Phase (WQD) Models: Stable operation within 160V–230V.
- Three-Phase (WQ) Models: Stable operation within 330V–380V.
- National Standard Motor: Equipped with high-efficiency, durable motors manufactured to national standards, ensuring consistent power and reliability for demanding sewage-handling tasks.
- Premium Brand Bearings: Features high-quality bearings that minimize friction and wear, contributing to smoother operation, lower noise levels, and extended service life under the stress of pumping solids-laden fluids.
- Silicon Carbide Mechanical Seals: Utilizes wear-resistant silicon carbide (SiC) seals. This material provides exceptional durability and resistance to abrasion from sand, grit, and other solids suspended in sewage, significantly enhancing sealing integrity and preventing leakage.
Model Number Instruction
The model code specifies the pump’s type and key performance parameters:
- WQ: Submersible Sewage Pump (Three-phase)
- WQD: Submersible Sewage Pump (Single-phase)
- First Number(s) (e.g., 10, 15): Rated Flow (m³/h)
- Second Number(s) (e.g., 9, 11, 15): Rated Head (m)
- Third Number (e.g., 0.55, 0.75, 1.1): Motor Power (kW)
Example: WQD10-9-0.55= Single-phase iron shell sewage pump with 10 m³/h flow, 9m head, and 0.55kW power.
Technical Specifications
Single-Phase (WQD) Sewage Pump Models
| No. | Model | Voltage (V) | Rated Flow (m³/h) | Rated Head (m) | Power (kW) | Pipe Dia. (mm) |
|---|---|---|---|---|---|---|
| 1 | WQD10-9-0.55 | 220 | 10 | 9 | 0.55 | 50 |
| 2 | WQD10-11-0.75 | 220 | 10 | 11 | 0.75 | 50 |
| 3 | WQD10-15-1.1 | 220 | 10 | 15 | 1.1 | 50 |
| 4 | WQD15-15-1.5 | 220 | 15 | 15 | 1.5 | 50 |
Three-Phase (WQ) Sewage Pump Models
| No. | Model | Voltage (V) | Rated Flow (m³/h) | Rated Head (m) | Power (kW) | Pipe Dia. (mm) |
|---|---|---|---|---|---|---|
| 1 | WQ10-9-0.55 | 380 | 10 | 9 | 0.55 | 50 |
| 2 | WQ10-11-0.75 | 380 | 10 | 11 | 0.75 | 50 |
| 3 | WQ10-15-1.1 | 380 | 10 | 15 | 1.1 | 50 |
| 4 | WQ15-15-1.5 | 380 | 15 | 15 | 1.5 | 50 |
Applications
- Domestic sewage drainage from homes, apartment buildings, and hotels.
- Drainage of wastewater from commercial kitchens, restaurants, and laundry facilities.
- Transfer of municipal or industrial wastewater containing suspended solids.
- Drainage of water containing small abrasive particles in construction, agricultural, and light industrial settings.
Why Choose DONGTAO WQ(D) Iron Shell Sewage Pump Series?
- Robust Construction: Durable iron shell provides strength and impact resistance for demanding sewage applications.
- Solid Handling Capability: Designed to efficiently pump liquids containing fibrous materials and small solids, preventing clogging.
- Adaptable Power: Wide voltage design ensures dependable performance even with unstable electrical supply, a common issue in remote or developing areas.
- Critical Seal Protection: Silicon carbide seals offer superior abrasion resistance, a vital feature for the gritty nature of sewage, reducing maintenance and downtime.
- Cost-Effective Solution: Offers a reliable and durable pumping solution for standard sewage applications at a competitive price point.
Contact Us for Sewage & Wastewater Solutions
To select the right WQ(D) model for your specific flow, head, and solids-handling requirements, or to request a quotation, please contact our technical sales team. We can help you configure the optimal pump for your wastewater management system.
